ILSCO ACO-90-500 Aluminum Compression Pigtail Adapter, 90 Degree Bend, 500 kcmil

Overview

Ilsco ACO-90-500 Aluminum Compression Pigtail Adapter, 90 Degree Bend, 500 kcmil

Product Specifications

• UPC: 783669009682
• Brand: Ilsco
• Manufacturer: Ilsco
• Catalog Number: ACO-90-500
• Item Number: 665581
• Product Type: Aluminum Compression Pigtail Adapter
• Connection Type: Compression
• Conductor Size: 500 kcmil
• Allowable Gauge Range: 500
• Material: Aluminum
• Finish: Tin Plated
• Bend Angle: 90 Degrees
• Pin Style: Bent Pin; Off-Center Pin
• Pin Feature: Knurled Pin for Greater Surface Contact
• Entry Type: Chamfered Entry
• Insulation: Supplied with Insulating Cover
• Oxide Inhibitor: Pre-Filled with DE-OX® Oxide Inhibiting Compound
• Color Code Feature: Color-Coded End Cap for Compression Die Identification
• Corrosion Resistance: Electro-Tin Plated
• Approval: UL; CSA
• Standards: California Proposition 65
• Application: Tight-Space Parallel Conductor Connections, 90 Degree Pigtail Adapter Installations, Compression Splicing, Copper/Aluminum Conductor Connections and Power Distribution Wiring
• Category: Compression Pigtail Adapters
• Features: Off-Center Pin Allows Connector Rotation in Tight Parallel Applications; Bent Pin Provides Added Installation Flexibility; Chamfered Entry Supports Easier Conductor Insertion; Insulating Cover Helps Eliminate Taping
• Catalog Description: Ilsco ACO-90-500 aluminum compression pigtail adapter features a 90-degree bent pin for flexible installation in tight spaces. It is designed for 500 kcmil conductor connections and includes tin plating, DE-OX compound and an insulating cover.
• Full Technical Description: Ilsco ACO-90-500 Aluminum Compression Pigtail Adapter; 90 Degree Bend Design for 500 kcmil Conductors; Aluminum Body with Electro-Tin Plated Finish for Corrosion Resistance; Off-Center Knurled Pin Improves Surface Contact and Allows Connector Rotation in Tight Parallel Applications; Chamfered Entry Supports Easy Conductor Insertion; Pre-Filled with DE-OX Oxide Inhibiting Compound; Supplied with Insulating Cover; UL and CSA Approved
• Manufacturer Brand: Ilsco
• Sub Category: Aluminum Compression Pigtail Adapters
• SKU Name: ilsco aco-90-500 aluminum 90 degree pigtail adapter

Resources

• Manufacturer Spec Sheet
