Overview

T&B 32003 Locktite Copper 2-Hole Lug

Product Specifications

• Catalog Description: LOCKTITE COPPER TWO-HOLE LUG, 14-8 AWG, 1/4 INCH STUD SIZE, LONG TONGUE
• Category: Lugs
• Full Technical Description: Long Tongue Type; Copper Material; Designed for Copper Conductors; 14 AWG Minimum Conductor Size; 8 AWG Maximum Conductor Size; 1 Conductor; 1/4 Inch Stud Size; 2 Pad Holes; Straight Pad Type; Filister Head Screw Type; 1-11/16 Inch Overall Length; Pad Size 1-1/4 Inch Length x 1/2 Inch Width x 1/8 Inch Thickness; UL and CSA Approved
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Mechanical Cable Lug
• Unspsc: 39121408
• UPC 12 Digit: 786210320038
• SKU Name: 32003-TB

Resources

• Manufacturer Specification Sheet
