AMP 34149 PLASTI-GRIP 22-16 AWG Ring Terminal

Overview

AMP 34149 PLASTI-GRIP 22-16 AWG Partially Insulated Ring Terminal

Product Specifications

• Catalog Description: CLOSED RING TONGUE TERMINAL, 22-16 AWG, #10 STUD, PARTIALLY INSULATED, TIN PLATED
• Category: Compression Connectors and Terminals
• Full Technical Description: PLASTI-GRIP Closed Ring Tongue Terminal; Designed for 22 to 16 AWG Copper Wire; #10 Stud Size; 4.82 mm [0.19 Inch] Stud Diameter; One-Hole Ring Tongue Design; Closed Barrel Type; Straight Terminal Orientation; Partially Insulated Construction; Insulation Support Retention Type; Tin Plating; 600 Volt Rating; Wire Size Range 0.26 to 1.65 mm² or 509 to 3260 CMA; Compatible Insulation Diameter Range 2.67 to 3.56 mm [0.105 to 0.14 Inch]; Tongue Thickness 0.79 mm [0.031 Inch]; Product Length 21.74 mm [0.86 Inch]; Operating Temperature Range 0 to 105 Deg C; Suitable for HVAC, Lighting, Power Management, Motor Drive, Control, and Industrial Applications
• Made In Usa:
• Manufacturer: TE Connectivity / AMP
• Manufacturer Brand: AMP
• Sub Category: Ring Terminal
• Unspsc:
• UPC 12 Digit:
• SKU Name: 34149

Resources

Product Specification Sheet
