Overview

3M 130C-3/4X30FT Scotch Linerless Rubber Splicing Tape 130C, 3/4" X 30 Ft, Black

Product Specifications

• UPC: 05400741717
• Finish: Black
• Dielectric Strength: 750 Volt per Mil
• Maximum Continuous Temperature: 90 Deg C
• Approval: UL
• Additional Information: Backing Material 0.76 Millimeter Ethylene Propylene Rubber; Temperature Rating 194 Deg F; Tensile Strength 250 PSI; Application Insulation
• Catalog Number: 130C-3/4X30FT
• Brand Name: Scotch[R]
• Type: High Voltage Insulating
• Voltage Rating: 69 Kilovolt
• Length: 30 Foot
• Width: 0.75 Inch
• Thickness: 30 Mil
• Material: Rubber
• Catalog Description: SCOTCH TAPE 130C IS A LINERLESS 30 MIL THICK, PREMIUM GRADE, RUBBER SPLICING TAPE USED FOR SPLICING AND TERMINATING CABLES AND WIRES. IT WITHSTANDS TEMPERATURES UP TO 194 F (90 C) WITH EMERGENCY OVERLOAD UP TO 266 F (130 C). THE TAPE HAS EXCELLENT ELECTRICAL AND MECHANICAL PROPERTIES TO PROVIDE MOISTURE SEAL PROTECTION.
• Category: Markers & Marking Tapes
• Full Technical Description: High Voltage Insulating Type; Rubber Material; Black Finish; 30 Foot; 0.75 Inch; 90 Deg C Max. Continuous Temperature; UL Approval; 69 Kilovolt Voltage Rating; 30 mil Thickness; 750 Volt Per mil Dielectric Strength; Backing Material 0.76 Millimeter Ethylene Propylene Rubber; Temperature Rating 194 Deg F; Tensile Strength 250 psi; Application Insulation; 130C Model
• Made In Usa: Yes
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Splicing and Insulating Tape
• Unspsc: 31201500
• UPC 12 Digit: 054007417170
• SKU Name: 3m 130c3/4x30ft

Resources

• Material Safety Data Sheet (MSDS)
• Product Brochure
• Manufacturer Spec Sheet
