T&B 54155BT Copper Tin Plated Blank Tongue Lug Standard 1/0 Pink Ph

Overview

T&B 54155BT Copper Tin Plated Blank Tongue Lug Standard 1/0 Pink Ph

Product Specifications

• UPC: 78621088489
• Stud Size: 1/2 INCH
• Color: PINK
• Die Index: 42
• Material: ELECTROLYTIC TIN PLATED WROUGHT COPPER
• Overall Length: 2-1/64 INCH
• Approval: UL, CSA
• Catalog Number: 54155BT
• Brand Name: Color-Keyed[R]
• Voltage Rating: 600 V TO 35 KV
• Conductor Material: COPPER
• Conductor Size: 1/0 AWG (CODE), 1/0 AWG (FLEX), 100 (NAVY, FLEX), 1 AWG (WELD, FLEX), 225/24 (FLEX), 133/0.0254 (FLEX), 0.389 (FLEX)
• Barrel Type: STANDARD
• Pad Size: 1-1/32 INCH L X 3/4 INCH W X 1/8 INCH THK
• Number Of Pad Holes: 1
• Catalog Description: COPPER BLANK TONGUE LUG, STANDARD BARREL, PEEP HOLE, MAX 35KV, WIRE SIZE 1/0 AWG, TIN PLATED, DIE CODE 42, DIE COLOR CODE PINK
• Category: Large Terminals & Connectors
• Full Technical Description: Electrolytic Tin Plated Wrought Copper Material; Pink Color; 2-1/64 Inch Overall Length; Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; 1/0 AWG (Code), 1/0 AWG (Flex), 100 (Navy, Flex), 1 AWG (Weld, Flex), 225/24 (Flex), 133/0.0254 (Flex), 0.389 (Flex) Conductor Size; 1/2 Inch Stud Size; 42 Die Index; 1-1/32 Inch L X 3/4 Inch W X 1/8 Inch Thk Pad Size; 1 Pad Hole(S); Standard Barrel Type; COLOR-KEYED[R] Brand
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 786210884899
• SKU Name: 54155bt t & b
