T&B 54206BT 4Awg Gray 2-Hole Copper Lug

Overview

T&B 54206BT 4Awg Gray 2-Hole Copper Lug

Product Specifications

• UPC: 78621084756
• Color: GRAY
• Die Index: 29
• Material: ELECTROLYTIC TIN PLATED WROUGHT COPPER
• Overall Length: 2-1/32 INCH
• Approval: UL, CSA
• Catalog Number: 54206BT
• Brand Name: Color-Keyed[R]
• Model: 542
• Voltage Rating: 600 V TO 35 KV
• Conductor Material: COPPER
• Conductor Size: 4 AWG (CODE), 4 AWG (FLEX), 91/24 (FLEX)
• Barrel Type: STANDARD
• Pad Size: 1-11/64 INCH L X 33/64 INCH W X 3/32 INCH THK
• Catalog Description: COPPER BLANK TONGUE LUG, STANDARD BARREL, PEEP HOLE, MAX 35KV, WIRE SIZE #4 AWG, TIN PLATED, DIE CODE 29, DIE COLOR CODE GRAY
• Category: Large Terminals & Connectors
• Full Technical Description: Electrolytic Tin Plated Wrought Copper Material; Gray Color; 2-1/32 Inch Overall Length; Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; 4 AWG (Code), 4 AWG (Flex), 91/24 (Flex) Conductor Size; 29 Die Index; 1-11/64 Inch L X 33/64 Inch W X 3/32 Inch Thk Pad Size; Standard Barrel Type; COLOR-KEYED[R] Brand; 542 Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 786210847566
• SKU Name: 54206bt t & b
