Product information
Overview
T&B 54260BT Copper Tin-Plated Blnk Tnge Lug Stnd 2/0 Black Ph
Product Specifications
- Catalog Description: COPPER BLANK TONGUE LUG, STANDARD BARREL, PEEP HOLE, MAX 35KV, WIRE SIZE 2/0 AWG, TIN PLATED, DIE COLOR CODE BLACK, DIE CODE 45
- Full Technical Description: Electrolytic Tin Plated Wrought Copper Material; Black Color; 3-13/16 Inch Overall Length; Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; 2/0 AWG (Code), 1/0 AWG (Flex), 275/24 (Flex) Conductor Size; 45 Die Index; 2-13/16 Inch L X 3/4 Inch W X 1/8 Inch Thk Pad Size; Standard Barrel Type; COLOR-KEYED[R] Brand; 542 Model
- Manufacturer: THOMAS & BETTS
- Sub Category: Compression Cable Lug
- Unspsc: 39121405
- UPC 12 Digit: 786210868677
- SKU Name: 54260bt t & b
