AF-400 4" ZA12 Zinc Alloy Expansion Fitting

Overview

AF-400 4" ZA12 Zinc Alloy Casted Expansion Fitting

Product Specifications

• Catalog Description: 4 INCH HUB EXPANSION FITTING, ZA12 ZINC ALLOY, 4 INCH LINEAR MOVEMENT
• Category: Expansion Joints
• Full Technical Description: AF Series Expansion Fitting; 4 Inch Hub Size; Expansion Type; ZA12 Zinc Alloy Casted Body and End Coupling; Natural Finish; Provides 4 Inch Maximum Linear Conduit Movement, 2 Inches in Either Direction; Designed for IMC or Rigid Conduit Installations; Helps Prevent Damage Caused by Temperature Fluctuation or Structural Movement; Includes Type A Phenolic Insulating Bushing; PTFE Synthetic Fiber Reinforced Gasket with Steel Washer; Tinned Braided Copper Ring; Rain, Water, and Concrete Tight Construction; Buy America BABA Compliant Status Valid Until December 2026
• Made In Usa:
• Manufacturer:
• Manufacturer Brand:
• Sub Category: Expansion Fitting
• Unspsc:
• UPC 12 Digit: 783936156071
• SKU Name: AF-400

Resources

Product Specification Sheet
