Appleton 570FIGSA FM7 Form 7 Aluminum Conduit Body Cover with Integral Gasket, 1-1/2 Inch

Product Specifications

• Catalog Description: FM7 Unilets Form-In-Place Clip Cover with Integral Gasket, 1-1/2 Inch Hub Size, Form 7, Screw-In Mounting, Cast Aluminum, Epoxy Powder Coated, NEMA 3R
• Category: Conduit Cover
• Full Technical Description: Form-In-Place Clip Cover with Integral Urethane Gasket; Aluminum Conduit Body Cover; Corrosion and Weather Resistant Type; 1-1/2 Inch Trade Size; Form 7 Form Type; Screw-In Mounting; Copper-Free Cast Aluminum Material; Zinc Electroplated Finish Reference; Epoxy Powder Coated Finish; FM7 and Wedge-Lok Brand Design; Unilets Sub Brand; NEMA 3R Enclosure Rating; Class I Division 2 Rating; Operating Temperature Rating -65 to 302 Degrees F; Captive Pan-Head Screws; Wedge-Lok Clips for Cover Seating; Wiring Capacity 3 Cubic Inches per NEC 314.16(A); Approved for Wet Locations; Can Be Used as Replacement Cover for Installed Bodies or in New Installations; Used on IMC and Rigid Conduit; Suitable for Commercial, Industrial, Hazardous, and Wet Location Applications; UL File Number E2527; CSA 65183; Class 4413-02; Applicable Standard NEC/CEC and NEMA FB-1
• Made In Usa: Yes
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body Cover
• Unspsc: 39131708
• UPC 12 Digit: 781381167888
• SKU Name: APP570FIGSA
