Appleton 880F 3" Iron Conduit Body Cover

Overview

Appleton 880F 3" Iron Conduit Body Cover

Product Specifications

• UPC: 78138174459
• Catalog Number: 880F
• Brand Name: FM8[R], Grayloy[TM]
• Type: Blank, Screw
• Trade Size: 2-1/2 Inch, 3 Inch
• Form Type: Form 8
• Material: Zinc Electroplated Chromated Epoxy Powder Coated Grayloy Iron
• Approval: UL 514A/514B, CSA C22.2
• Additional Information: Application Compile with a Wide Range of Classified Area Requirement, Corrosion Resistant Ideal Indoor or Outdoor, for Pulling of Wire, Connect Conduit Length and Change Direction of Conduit Run, Provide Access for Maintenance
• Catalog Description: FM8 GRAYLOY-IRON UNILETS BLANK COVER WITH SCREW, HUB SIZE: 2-1/2 - 3 IN, FORM: 8, MOUNTING: SCREW-IN, MATERIAL: CAST GRAYLOY-IRON, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER COAT), COLOR: GRAY, STANDARD: UL 514A, UL 51
• Category: Steel Conduit Bodies & Covers
• Full Technical Description: Blank Type; Zinc Electroplated/Chromate/Epoxy Powder Coated Cast Grayloy-Iron Material; UL 514A/B, CSA C22.2 Approval; 2-1/2 Inch, 3 Inch Trade Size; Form 8 Form Type; FM8[TM] Brand; Enclosure Rating Class I Div 2, NEMA 3R; Used on Imc/Rigid Conduit; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body Cover
• Unspsc: 39131708
• UPC 12 Digit: 781381744591
• SKU Name: app 880f

Resources

• Manufacturer Spec Sheet
