Overview

Appleton AMD4664A 6X6 Aluminum Mounting Plate

Product Specifications

• UPC: 78138190349
• Catalog Number: AMD4664A
• Brand Name: Appleton.
• Type: ALUMINUM 90 DEG MOUNTING PLATE
• Used On: AGUB-664A INSTRUMENT/METER ENCLOSURE
• Catalog Description: ENCLOSURE MOUNTING PLATE, TYPE 90 DEG MOUNTING PLATE, USED ON AGUB-664A INSTRUMENT/METER ENCLOSURE, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST-IGNITIONPROOF, ENCLOSURE CLASS I DIV 1 AND 2 GROUP B C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 4/4X/7BCD/9EFG, SIZE 7 INCH L X 7 INCH W X 6.5 INCH H, MATERIAL ALUMINUM
• Category: Enclosure General Accessories
• Full Technical Description: Mounting Plate, 90 Degree Type; Agub Instrument and Meter Enclosure Used on; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 4/4X/7BCD/9EFG Enclosure; Explosionproof, Dust Ignitionproof; Material Aluminum; Application Hazardous Location; Applicable Standard Nec/Cec, UL 1203, CSA C22.2
• Made In Usa: Yes
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Box/Enclosure General Accessories
• Unspsc: 39121302
• UPC 12 Digit: 781381903493
• SKU Name: app amd4664a

Resources

• Manufacturer Spec Sheet
