Appleton AMPG121212 12X12X12 Galvanized Mounting Plate

Overview

Appleton AMPG121212 12X12X12 Galvanized Mounting Plate

Product Specifications

• UPC: 78138190348
• Catalog Number: AMPG121212
• Brand Name: Appleton.
• Type: GALVANIZED STEEL MOUNTING PLATE
• Used On: AGUB-121212A INSTRUMENT/METER ENCLOSURE
• Catalog Description: ENCLOSURE MOUNTING PLATE, TYPE STANDARD MOUNTING PLATE, USED ON AGUB-121212A INSTRUMENT/METER ENCLOSURE, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST-IGNITIONPROOF, ENCLOSURE CLASS I DIV 1 AND 2 GROUP B C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 4/4X/7BCD/9EFG, SIZE 13.62 INCH L X 13.62 INCH W X 15.75 INCH H, MATERIAL GALVANIZED STEEL
• Category: Enclosure General Accessories
• Full Technical Description: Mounting Plate, Standard Type; Agub/Ngub Instrument and Meter Enclosure Used on; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 4/4X/7BCD/9EFG Enclosure; Explosionproof, Dust Ignitionproof; Overall Dimension 12 Inch X 12 Inch X 12 Inch; Material Galvanized Steel; Applicable Standard Nec/Cec, UL 1203, UL (Canada and Us), CSA C22.2
• Made In Usa: Yes
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Box/Enclosure General Accessories
• Unspsc: 39121302
• UPC 12 Digit: 781381903486
• SKU Name: app ampg121212

Resources

• Manufacturer Spec Sheet
