Appleton BC150-A 1-1/2" Aluminum C Mogul Unilet (Body, Cover & Gasket)

Overview

Appleton BC150-A 1-1/2" Aluminum C Mogul Unilet (Body, Cover & Gasket)

Product Specifications

• UPC: 78138174333
• Size: 13.94 Inch L x 3.13 Inch W x 3.75 Inch H
• Installation: Threaded
• Material: Epoxy Powder Coated Copper Free Aluminum Body, Neoprene Gasket, Stainless Steel Screw
• Approval: UL 514B, CSA C22.2, NEC, CEC
• Used On: Rigid Conduit/IMC
• Additional Information: Applicable Standard NEMA FB-1; Capacity 93 Cu Inch; Application Pulling of Large and Heavy Conductor, Pulling Straight/45 Deg/90 Deg Angle Turn and/or Making Tap and Splice
• Catalog Number: BC150-A
• Brand Name: Unilet[R]
• Access Opening: Side
• Configuration: C
• Cover Type: Epoxy Powder Coated Copper Free Aluminum
• Hub Location: Straight
• Number Of Hubs: 2
• Hub Size: 1-1/2 Inch
• Catalog Description: MOGUL UNILETS TYPE C NEC 8X CONDUIT OUTLET BODY WITH ASSEMBLED COVER AND GASKET, HUB SIZE: 1-1/2 IN, LENGTH: 13.94 IN, WIDTH: 3.13 IN, HEIGHT: 3-3/4 IN, MATERIAL: ALUMINUM, FINISH: EPOXY POWDER COAT, CONNECTION: TAPERED FEMALE THREADED, S
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Epoxy Powder Coated Copper-Free Aluminum (Body), Stainless Steel (Screw) Material; 13.94 Inch Length X 3.13 Inch Width X 3.75 Inch Height Size; Imc/Threaded Rigid Metal Conduit Used on; 1-1/2 Inch Hub Size; Threaded Installation; C Configuration; 2 Hub(S); UL 514B, CSA C22.2 Approval; Straight Hub Location; Side Access Opening; UNILETS[R] Brand; Wire Size (3) 3/0 AWG; Capacity 93 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body
• Unspsc: 39131708
• UPC 12 Digit: 781381743334
• SKU Name: app bc150a
