Appleton BC200-A 2" Aluminum C Mogul Unilet

Overview

Appleton BC200-A 2" Aluminum C Mogul Unilet

Product Specifications

• UPC: 78138174334
• Hub Size: 2 Inch
• Size: 17.94 Inch Length x 3.13 Inch Width x 4.44 Inch Height
• Installation: Threaded
• Material: Epoxy Powder Coated Copper-Free Aluminum (Body), Neoprene (Gasket), Stainless Steel (Screw)
• Form Type: Mogul
• Approval: UL 514B, CSA C22.2, NEC, CEC
• Used On: IMC/Rigid Conduit
• Additional Information: Capacity 145 Cubic Inch; Application Pulling of Large and Heavy Conductor, Pulling Straight/45 Degree/90 Degree Angle Turn and/or Making Tap and Splice; Applicable Standard NEMA FB-1
• Catalog Number: BC200-A
• Brand Name: Appleton
• Model: BC
• Access Opening: Side
• Configuration: C
• Cover Type: Epoxy Powder Coated Copper-Free Aluminum
• Hub Location: Straight
• Number Of Hubs: 2
• Catalog Description: MOGUL UNILETS TYPE C NEC 8X CONDUIT OUTLET BODY WITH ASSEMBLED COVER AND GASKET, HUB SIZE: 2 IN, LENGTH: 17.94 IN, WIDTH: 3.13 IN, HEIGHT: 4.44 IN, MATERIAL: ALUMINUM, FINISH: EPOXY POWDER COAT, CONNECTION: TAPERED FEMALE THREADED, STANDA
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Epoxy Powder Coated Copper-Free Aluminum (Body), Stainless Steel (Screw) Material; 17.94 Inch Length X 3.13 Inch Width X 4.44 Inch Height Size; Imc/Threaded Rigid Metal Conduit Used on; 2 Inch Hub Size; Threaded Installation; C Configuration; 2 Hub(S); UL 514B, CSA C22.2 Approval; Straight Hub Location; Side Access Opening; UNILETS[R] Brand; Wire Size (3) 300 MCM; Capacity 143 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body
• Unspsc: 39131708
• UPC 12 Digit: 781381743341
• SKU Name: app bc200a

Resources

• Manufacturer Spec Sheet
