Appleton BUB250A 2-1/2" Aluminum UB Mogul Unilet Conduit Body with Cover & Gasket

Overview

Appleton BUB250A 2-1/2" Aluminum UB Mogul Unilet Conduit Body with Cover & Gasket

Product Specifications

• Catalog Description: IMC/Rigid Mogul Conduit Body; UB Configuration; Back Access Opening; 2 Hubs; Threaded Connections; Aluminum Construction; Cover and Gasket Included.
• Category: LBD/MOGUL
• Full Technical Description: Mogul Conduit Outlet Body; Appleton NEC 6x8x Series; UB Configuration; 2-1/2 Inch Trade Size; 2 Hubs; 45 Degree Hub Location; Back Access Opening; Threaded Connection Type; Designed for IMC and Rigid Metal Conduit; Aluminum Composition; Epoxy Powder Coated Copper-Free Aluminum Cover; Cover Included; Gasket Included; 22.88 Inch Length x 4.63 Inch Width x 7.06 Inch Height; Net Weight 14 Pounds; Gross Weight 14 Pounds; UL and CSA Approved; Suitable for Hazardous Locations; Larger Body Designed to Facilitate Pulling Large and Heavy Conductors; Suitable for Straight Pulls, 45 Degree or 90 Degree Turns, Taps, and Splices

• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton
• Sub Category: UB Mogul Conduit Body

• UPC: 78138147444

• SKU Name: BUB250A

Resources

Manufacturer Specification Sheet
