Appleton CESD-6023 Explosion-Proof Receptacle

Overview

Appleton CESD-6023 Explosion-Proof Receptacle

Product Specifications

• UPC: 78138118830
• Cover Type: Spring
• Mating Plug: CPH
• Enclosure: Class I Div 1 and 2 Group C D
• Approval: UL1010/894/1682/1686, CSA C22.2
• Additional Information: Overall Dimension 9.31 Inch W x 12.75 Inch H; Application Lighting System, Conveyor, Heater, Motor Generator Set, Air Conditioner, Compressor, Pump, Stationary Equipment
• Catalog Number: CESD-6023
• Type: Feed Through
• Voltage Rating: 125 to 250 VAC
• Current Rating: 60 Ampere
• Power Rating: 1-1/2 HP at 125/250 VAC, 1-1/2 HP at 480 VAC
• Number Of Poles: 3
• Number Of Wires: 2
• Hub Size: 1-1/4 Inch
• Catalog Description: PIN AND SLEEVE RECEPTACLE ASSEMBLY, TYPE FEED THROUGH, VOLTAGE RATING 125 TO 250 VAC, CURRENT RATING 60 AMPERE, NUMBER OF POLES 3, NUMBER OF WIRES 2, HUB SIZE 1-1/4 INCH, ENCLOSURE CLASS I DIV 1 AND 2 GROUP C D, APPROVAL UL 894/1010/1682/1686, CSA C22.2, APPLICATION LIGHTING SYSTEMS, CONVEYORS, HEATERS, MOTOR-GENERATOR SETS, AIR CONDITIONERS, COMPRESSORS, PUMPS, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, MATERIAL CERAMIC BURNISHED COPPER-FREE ALUMINUM, OVERALL SIZE 9.31 INCH W X 12.75 INCH H
• Category: Pin & Sleeve Devices
• Full Technical Description: Vertical Feed-Through Type; 1-1/4 Inch Hub Size; 2 Wire(S); UL 894/1010/1682/1686, CSA C22.2 Approval; 125/250 Volt AC 1-Phase Voltage Rating; Class I Div 1 and 2 Group D Enclosure; 60 Amp Current Rating; Spring Cover Type; 1-1/2 HP Power Rating; 3 Pole(S); Cph Mating Plug; SLIDE-LOK[R] Brand; Overall Dimension 9.31 Inch Width X 12.75 Inch Height; Material Zinc Electroplate/Chromate/Epoxy Powder Coated Malleable Iron (Mounting Box), Ceramic Burnished Copper-Free Aluminum (Receptacle); Application Lighting System, Conveyor, Heater, Motor Generator Set, Air Conditioner, Compressor, Pump; Applicable Standard Nec/Cec; CESD Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Pin and Sleeve Receptacle Assembly
• Unspsc: 39121406
• UPC 12 Digit: 781381188302
• SKU Name: app cesd6023
