Appleton CL-50MN 1/2" 1-Hole Malleable ClAMP

Overview

Appleton CL-50MN 1/2" 1-Hole Malleable Clamp

Product Specifications

• UPC: 78138187572
• Used On: IMC/Rigid Conduit
• Additional Information: Application Commercial and Industrial; Applicable Standard CEC
• Catalog Number: CL-50MN
• Type: 1-Hole
• Trade Size: 1/2 Inch
• Hole/Bolt Size: 0.25 Inch
• Width: 0.63 Inch
• Height: 0.75 Inch
• Material: Hot Dip Galvanized Malleable Iron
• Approval: CSA
• Catalog Description: CLAMP, CABLE SIZE: 1/2 IN, CABLE TYPE: RMC, IMC, EMT, MATERIAL: MALLEABLE IRON, FINISH: HOT DIPPED GALVANIZED, DIMENSIONS: 0.63 IN WIDTH X 3/4 IN HEIGHT, STANDARD: CSA C22.2 NO. 18.4, CSA 065178, FOR USED TO SUPPORT RUNS OF RMC, IMC AND E
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: 1-Hole Type; Hot Dip Galvanized Malleable Iron Material; 0.63 Inch; 0.75 Inch; Imc/Rigid Metal Conduit Used on; CSA C22.2 Approval; 1/2 Inch Trade Size; 0.25 Inch Hole/Bolt Size; Application Commercial/Industrial, Hazardous Location; Applicable Standard CEC
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Rigid/EMT Conduit Strap
• Unspsc: 39121701
• UPC 12 Digit: 781381875721
• SKU Name: app cl50mn

Resources

• Manufacturer Spec Sheet
