Appleton CPP516 2Wr 3-Pilot Light Pin&Sleeve Plug

Overview

Appleton CPP516 2Wr 3-Pilot Light Pin&Sleeve Plug

Product Specifications

• UPC: 78138184529
• Maximum Cable Outer Diameter: 0.639 Inch
• Material: Copper Free Aluminum
• Mating Receptacle: CPS
• Enclosure: Class I Div 1 and 2 Group C D
• Approval: UL
• Catalog Number: CPP516
• Brand Name: Contender[R]
• Voltage Rating: 125 to 250 VAC/18 VDC
• Current Rating: 20 Ampere
• Power Rating: 1 HP
• Number Of Phases: 3
• Number Of Poles: 2
• Minimum Cable Outer Diameter: 0.538 Inch
• Catalog Description: CPP SERIES STRAIGHT PLUG, NUMBER OF POLES: 3, NUMBER OF WIRES: 2, AMPERAGE RATING: 20 AMP, VOLTAGE RATING: 125 - 250 VAC, 18 VDC, MATERIAL: COPPERFREE ALUMINUM, CONNECTION: PRESSURE WIRE TERMINAL, MOTOR HORSEPOWER: 1 HP, DIMENSIONS: 1.86 I
• Category: Pin & Sleeve Devices
• Full Technical Description: Neoprene Material; 0.538 Inch min. Cable Outer Diameter; 0.639 Inch Max. Cable Outer Diameter; 2 Wire(S); UL 1010, CSA C22.2 Approval; 125/250 Volt AC, 18 Volt DC Voltage Rating; Class I Div 1 and 2 Group C D Enclosure; 20 Amp Current Rating; 1 HP Power Rating; 3 Pole(S); Cps Mating Receptacle; Overall Dimension 4.81 Inch Length X 1.86 Inch Height; Application Air Conditioner, Compressor, Heater; Applicable Standard Nec/Cec
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Pin and Sleeve Plug
• Unspsc: 39121402
• UPC 12 Digit: 781381845298
• SKU Name: app cpp516
