Appleton EFDC175-3MS 3P Manual Contactor

Overview

Appleton EFDC175-3MS 3P Manual Contactor

Product Specifications

• UPC: 78138127410
• Catalog Number: EFDC175-3MS
• Brand Name: Appleton
• Model: EFD
• Type: Manual Contactor, 3-Pole, Feed-Through
• Used On: EDS Series Manual Motor Starter
• Constructional Feature: Explosionproof, Dust Ignitionproof
• Enclosure: Class I Div 1 Group C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/3R/7C/7D/9E/9F/9G
• Additional Information: Switch Rating 30 Amp 120/240/480/600 Volt AC, 3/7-1/2/15 HP; Hub Size 3/4 Inch; Material Gray Epoxy Powder Coated Malleable Iron; Approval UL (Canada and US), UL 508/698/1203, CSA C22.2
• Catalog Description: MANUAL CONTACTOR, NUMBER OF POLES: 3, HUB SIZE: 3/4 IN, SWITCH RATING: 30 AMP AT 250 VAC/VDC, 20 AMP AT 600 VAC, 1 HP AT 115 VAC, 2 HP AT 230 VAC, 3 HP AT 460-575 VAC, STANDARD: UL 508, UL 698, UL 1203, CSA NUMBER C22.2 14-M, C22.2 NO
• Category: Special Purpose Contactors
• Full Technical Description: 3-Pole, Manual Contactor, Feed-Through Type; Eds Manual Motor Starter Used on; Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/3R/7CD/9EFG Enclosure; Explosionproof, Dust Ignitionproof; Hub Size 3/4 Inch; Switch Rating 30 Amp 600 Volt AC, 3 HP 120 Volt AC, 7-1/2 HP 240 Volt AC, 15 HP 480/600 Volt AC; Applicable Standard Nec/Cec, UL (Canada and Us), UL 508/698/1203, CSA C22.2; EFD Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Motor Starter Accessories
• Unspsc: 39121521
• UPC 12 Digit: 781381274104
• SKU Name: app efdc1753ms

Resources

• Manufacturer Spec Sheet
