Appleton JGBNA Amber Jewel & Guard Assembly

Overview

Appleton JGBNA Amber Jewel & Guard Assembly

Product Specifications

• UPC: 78138176582
• Catalog Number: JGBNA
• Brand Name: Appleton.
• Type: AMBER PILOT LIGHT JEWEL/GUARD ASSEMBLY
• Used On: CONTENDER. OR EFD/EFDB SERIES OR INTRAGROUND. N1/N2 SERIES PILOT LIGHT
• Enclosure: CLASS I DIV 1 AND 2 GROUP B C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III
• Catalog Description: PILOT LIGHT JEWEL/GUARD ASSEMBLY, TYPE AMBER JEWEL/GUARD ASSEMBLY, USED ON ECS CONTROL STATION, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST IGNITIONPROOF, ENCLOSURE CLASS I DIV 1 2 GROUP B C D, CLASS II DIV 1 2 GROUP E F G, CLASS III, CSA TYPE 3R 7B/7C/7D/9E/9F/9G, BODY MATERIAL COPPER FREE ALUMINUM, PUSHBUTTON MATERIAL ALUMINUM UPPER BARREL PHELONIC LOWER BARREL, DUST CAP MATERIAL NEOPRENE BUTTON, PILOT LIGHT GUARD AND BODY MATERIAL ALUMINUM AND TEMPERED GLASS JEWEL, CLAMPING RING MATERIAL STEEL, SELECTOR SWITCH MATERIAL ALUMINUM OPERATOR MECHANISM AND NYLON CAM, BODY AND COVER FINISH BAKED EPOXY PAINT, OPERATORS FINISH NATURAL, INCLUSION NEOPRENE WEATHER BOOT, 120 VAC LAMP
• Category: Push Button, Pilot Light, Selector Switch Accessories
• Full Technical Description: Jewel and Guard Assembly Type; Splsamb Pilot Light Used on; Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III Enclosure; Explosionproof; Color Amber; Material Tempered Glass (Jewel), Copper-Free Aluminum (Guard); Applicable Standard Nec/Cec
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Pushbutton Accessories
• Unspsc: 39121534
• UPC 12 Digit: 781381765824
• SKU Name: app jgbna

Resources

• Manufacturer Spec Sheet
