Appleton SSBASL23 3-Position 4Ckt Momentary Left Selector Switch

Overview

Appleton SSBASL23 3-Position 4Ckt Momentary Left Selector Switch

Product Specifications

• UPC: 78138163442
• Throw: LEFT-CENTER-RIGHT
• Actuator Material: ALUMINUM
• Enclosure: CLASS I DIV 1 AND 2 GROUP C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 3/7C/7D/9E/9F/9G
• Catalog Number: SSBASL23
• Brand Name: Appletion[R]
• Type: KNOB
• Size: 1/2 INCH
• Contact Rating: 600 VAC 10 AMPERE
• Operation Type: MOMENTARY/MAINTAINED/MAINTAINED
• Contact Configuration: 2NO-2NC
• Number Of Positions: 3
• Catalog Description: EXPLOSIONPROOF SELECTOR SWITCH ASSEMBLY, TYPE KNOB, SIZE 1/2 INCH, CONTACT RATING 600 VAC 10 AMPERE, OPERATION TYPE MOMENTARY/MAINTAINED/MAINTAINED, CONTACT CONFIGURATION 2NO-2NC, NUMBER OF POSITIONS 3, THROW LEFT-CENTER-RIGHT, ACTUATOR MATERIAL ALUMINUM, ENCLOSURE CLASS I DIV 1 AND 2 GROUP C D, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 3/7CD/9EFG, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF, DUST IGNITIONPROOF
• Category: Selector Switch Complete Assemblies
• Full Technical Description: Momentary/Spring Return/Maintained Operation Type; Malleable Iron Enclosure Material; 600 Volt AC 10 Amp Contact Rating; UL 508/698/1203, CSA C22.2 Approval; Class I Div 1 Group C D, Class I Div 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/7CD/9EFG Enclosure; 3 Position(S); Natural Copper-Free Aluminum Actuator Material; Left-Center-Right Throw; Legend Hand/Off/Auto; Number of Circuits 4; Material Nylon (CAM), Sealed Phenolic Contact (Block); Applicable Standard Nec/Cec
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Explosionproof Non Illuminated Selector Switch
• Unspsc: 39122217
• UPC 12 Digit: 781381634427
• SKU Name: app ssbasl23

Resources

• Manufacturer Spec Sheet
