Appleton STN-125SR 1-1/4" Straight Insulated Liquidtight Con

Overview

Appleton STN-125SR 1-1/4" Straight Insulated Liquidtight Con

Product Specifications

• UPC: 78138150161
• Standard Package: 10
• Approval: UL 514-B, CSA C22.2
• Used On: FLEXIBLE METALLIC CONDUIT
• Additional Information: APPLICABLE STANDARD NEC 501-4(B), NEC 502-4(A)(2), NEC 503-3(A)
• Catalog Number: STN-125SR
• Brand Name: Appleton[R]
• Model: STN
• Trade Size: 1-1/4 INCH
• Connector Type: STRAIGHT
• Connector Material: ZINC ELECTROPLATED DICHROMATE ALUMINUM POLYMER ENAMELED MALLEABLE IRON
• Throat Type: INSULATED
• Mesh Material: STAINLESS STEEL
• Catalog Description: APPLETON STN SERIES STRAIGHT LIQUIDTIGHT CONNECTOR WITH WIRE MESH STRAIN RELIEF, SIZE: 1-1/4-11-1/2, MATERIAL: MALLEABLE IRON, FINISH: CHROMATE, EPOXY POWDER COAT/ZINC ELECTROPLATED, INSULATION: INSULATED THROAT, DIMENSIONS: 2.63 IN LENGTH X 2.31 IN HEIGHT, OUTSIDE DIAMETER: 1.63 - 1.66 IN, HOLE DIAMETER: 1.69 - 1.84 IN, WALL THICKNESS: 0.06 - 0.31 IN, STANDARD: CLASS I, DIVISION 2, UL 514B, E14814, CSA C22.2 NO. 18.3, 065178, NEMA FB-1, FOR LIQUIDTIGHT FLEXIBLE METAL CONDUIT TO SHEET METAL ENCLOSURES
• Category: Liquid Tight Flex. Conduit Fittings
• Full Technical Description: Liquid Tight Flexible Metal Conduit Used on; UL 514B, CSA C22.2 Approval; Straight Connector Type; 1-1/4 Inch Trade Size; Insulated Throat Type; Stainless Steel Mesh Material; Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron Connector Material; Outside Diameter 1.63 to 1.66 Inch; Enclosure Rating Class I Div 2, Class I Zone 2, Class II Div 1 and 2, Class III Div 1 and 2; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard Nec/Cec, NEMA FB-1; STN-SR Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Liquidtight Flexible Conduit Connector with Grip
• Unspsc: 39121420
• UPC 12 Digit: 781381501613
• SKU Name: app stn125sr
