Appleton TB18 1/2" Conduit Body

Overview

Appleton TB18 1/2" Conduit Body

Product Specifications

• UPC: 78138174439
• Size: 5.94 Inch L x 2.59 Inch H
• Installation: Threaded
• Material: Electro Zinc Plated Dichromate Epoxy Powder Coated Gray Iron Alloy Body, Neoprene Gasket, Stainless Steel Cover Screw
• Form Type: Form 8
• Approval: UL 514A/514B, CSA C22.2, NEC, CEC
• Used On: Rigid Conduit/IMC
• Additional Information: Applicable Standard NEMA FB-1; Capacity 6 Cu Inch; Application Serve as Pulling Fitting, Make Bends in Conduit System, Provide Openings for Splicing, Connect and Change Direction of Conduit Run, Allow Connections for Branch Run, Permit Access to Conductor
• Catalog Number: TB18
• Brand Name: Unilet[R], FM8[TM]
• Access Opening: Back
• Configuration: TB
• Cover Type: Electro Zinc Plated Dichromate Epoxy Powder Coated Gray Cast Iron Alloy
• Hub Location: Tee
• Number Of Hubs: 3
• Hub Size: 1/2 Inch
• Catalog Description: IMC/RIGID CONDUIT BODY, ACCESS OPENING TEE BACK, CONFIGURATION TB, COVER TYPE ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED GRAY CAST IRON, HUB LOCATION TEE, NUMBER OF HUBS 3, HUB SIZE 1/2 INCH, SIZE 5.94 INCH L X 2.59 INCH H, INSTALLATION THREADED, MATERIAL ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED GRAY IRON BODY, NEOPRENE GASKET, STAINLESS STEEL SCREW, FORM TYPE FORM 8, APPROVAL UL 514A/514B/E2527, CSA C22.2, USED ON IMC/RIGID CONDUIT, APPLICABLE STANDARD NEC/CEC, NEMA FB-1, CAPACITY 6 CU INCH
• Category: Steel Conduit Bodies & Covers
• Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Grayloy-Iron (Body), Stainless Steel (Cover Screw) Material; 5.94 Inch Length X 2.59 Inch Height Size; Imc/Rigid Conduit Used on; 1/2 Inch Hub Size; Threaded Installation; TB Configuration; 3 Hub(S); UL 514A/B, CSA C22.2 Approval; Tee Hub Location; Form 8 Form Type; Back Access Opening; FM8[TM] Brand; Capacity 6 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body
• Unspsc: 39131708
• UPC 12 Digit: 781381744393
• SKU Name: app tb18

Resources

• Manufacturer Spec Sheet
