Appleton AAU-4MVNS A-51 400W MH/MV Hazardous-Location Fixture

Overview

Appleton AAU-4MVNS A-51 Series 400W Metal Halide or Mercury Vapor Hazardous-Location Light Fixture

Product Specifications

• Catalog Description: A-51 Series Hazardous-Location Light Fixture, 400W Metal Halide or Mercury Vapor, 300V, Class II Divisions 1 and 2, Groups E, F, and G
• Category: Lighting
• Full Technical Description: Hazardous-Location Industrial Light Fixture; Catalog Number AAU-4MVNS; Appleton A-51 Series; 400 Watt Lamp Rating; 300 Volt Rating; Compatible with 400W Metal Halide and 400W Mercury Vapor Lamps; Class II Division 1 and Division 2 Rating; Suitable for Groups E, F, and G Hazardous Atmospheres; 400W Metal Halide Configuration Rated T3B; 400W Mercury Vapor Configuration Rated T3C; Maximum Surface Temperature 135 Degrees C; Fixture Unit Weight 21.8 lb; Compatible with Appleton AAGU-5 Protective Guard; Compatible with Standard, 30-Degree Angle, and High-Bay Reflectors; Compatible High-Bay Reflector Reference AARE-5HB; Designed for Hazardous Industrial Lighting Applications
• Manufacturer: Emerson / Appleton Electric
• Manufacturer Brand: Appleton
• Sub Category: Hazardous-Location HID Light Fixture
• SKU Name: AAU-4MVNS

Resources

Manufacturer Specification Sheet
