Appleton CES60B 60A Receptacle Back Box

Overview

Appleton CES60B 60A 120/125V Slide-Lok Pin-and-Sleeve Receptacle Back Box

Product Specifications

• Catalog Description: Pin-and-Sleeve Receptacle Back Box; 60 Amp Device Rating; 120/125 Volts AC; 1-1/4 Inch Hub; For Slide-Lok CES Series Receptacles; Explosion-Proof Construction.
• Category: Plugs & Receptacles
• Full Technical Description: Pin-and-Sleeve Receptacle Back Box and Body Assembly; Appleton Slide-Lok CES Series; 60 Amp Device Rating; 120/125 Volt AC Rating; 1-1/4 Inch Feed-Through Hub Size; Designed for Slide-Lok CES Series Pin-and-Sleeve Receptacles; Epoxy Powder Coated Copper-Free Aluminum Body Material; Explosion-Proof Construction; Enclosure Rating Class I Division 1 and 2 Groups C and D; UL 894, UL 1203, UL 1682, and UL 1686 Approved; CSA C22.2 Approved; Applicable Standards NEC and CEC; Suitable for Lighting Systems, Conveyors, Heaters, Motor-Generator Sets, Air Conditioners, Compressors, Pumps, and Other Portable or Stationary Equipment
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Pin-and-Sleeve Receptacle Back Box
• Unspsc: 39121406
• UPC 12 Digit: 781381628099
• SKU Name: CES60B

Resources

Manufacturer Specification Sheet
