Appleton CESD60B Slide-Lok CESD Series Pin & Sleeve Receptacle Body Assembly, 60 Amp, 1-1/4" Hub

Overview

Appleton CESD60B Slide-Lok CESD Series Pin & Sleeve Receptacle Body Assembly, 60 Amp, 1-1/4" Hub, Explosionproof Industrial Back Box

Product Specifications

• Brand: Appleton
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Model: CESD
• Part Number (MPN): CESD60B
• Catalog Number: CESD60B
• UPC: 78138162811
• Device Rating: 60 A
• Hub Size: 1-1/4 inch
• Material: Zinc Electroplated, Chromate and Epoxy Powder Coated Malleable Iron
• Constructional Feature: Explosionproof
• Used On: Slide-Lok CESD Series Pin & Sleeve Receptacles
• Voltage Rating: 120/125 V AC
• Standards/Approvals: UL 894, UL 1203, UL 1682, UL 1686, CSA
• Enclosure Rating: Class I Div 1 and 2 Group C & D
• Category: Pin & Sleeve Devices
• Sub-Category: Pin and Sleeve Back Box
• Application: Lighting systems, conveyors, heaters, motor generator sets, air conditioners, compressors, pumps, and other portable or stationary equipment
• Full Technical Description: Appleton CESD60B is a 60 Amp Slide-Lok CESD series pin-and-sleeve back box constructed from zinc-electroplated, chromate- and epoxy powder-coated malleable iron. Features a 1-1/4" feed-through hub, explosionproof design, and approvals to UL 894/1203/1682/1686 and CSA standards. Designed for industrial applications including lighting, motor-generator sets, compressors, and pumps.
