Appleton dtx181206

Overview

Appleton DTX181206 18X12X6 Iron Junction Box

Product Specifications

• Part Number: DTX181206
• UPC / GTIN: 78138184393
• UPC: 78138184393
• Depth: 6-9/32 INCH
• Depth in inch: 6.28125
• Material: CAST IRON
• Finish: HOT DIP GALVANIZED
• Enclosure: NEMA 4/9EFG
• Mounting: LUGS, SURFACE
• Cover Type: GASKETED, BOLT ON
• Approval: UL 886
• Height in inch - UOM: in
• Width in inch - UOM: in
• Depth in inch - UOM: in
• Additional Information: APPLICATION COAL STORAGE UNIT, GRAIN ELEVATOR, TEXTILE FACTORY, TISSUE PAPER MILL; CONSTRUCTIONAL FEATURE DUST IGNITION PROOF, WATER TIGHT
• Brand Name: Appleton.
• Model: DTX
• Type: FLANGED
• Height: 20-5/8 INCH
• Height in inch: 20.625
• Width: 14-5/8 INCH
• Width in inch: 14.625
• CATALOG DESCRIPTION: CAST JUNCTION BOX, HUB SIZE 3/4 INCH, OVERALL SIZE 20.63 INCH L X 14.63 INCH W X 6.59 INCH D, INNER SIZE 18 INCH L X 12 INCH W X 6 INCH D, WALL THICKNESS 0.28 INCH (TOP), 0.31 INCH (COVER), 0.28 INCH (BACK), COVER TYPE GASKETED BOLT-ON, ENCLOSURE CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, NEMA 4/9EFG, BODY MATERIAL CAST IRON, BODY FINISH HOT DIP GALVANIZED, COVER MATERIAL CAST IRON, COVER FINISH HOT DIP GALVANIZED, MOUNTING SURFACE WITH LUG, APPROVAL UL 886/1203, APPLICATION COAL STORAGE UNIT, GRAIN ELEVATOR, TEXTILE FACTORY, TISSUE PAPER MILL, CONSTRUCTIONAL FEATURE DUST-IGNITIONPROOF, WATERTIGHT
• Full Technical Description: 20.63 Inch Length X 14.63 Inch Width X 6.59 Inch Depth Overall Size; 18 Inch Length X 12 Inch Width X 6 Inch Depth Inner Size; 3/4 Inch Hub Size; UL 886 Approval; Surface Mounting; Class II Div 1 and 2 Group E F G, Class III, NEMA 4/9FG Enclosure; Gasketed Cover Type; Cast Iron Body Material; Cast Iron Cover Material; 0.28 Inch Wall Thickness; Hot Dip Galvanized Body Finish; 18 Inch Cover Opening Diameter; Hot Dip Galvanized Cover Finish; Constructional Feature Dust Ignitionproof, Water Tight; Application Grain Elevator, Grain Storage Area, Paper Mill, Coal Storage Facility, Textile Factory; Applicable Standard Nec/Cec; DTX Model
• Manufacturer: Appleton Electric
• Product Description: Appleton DTX181206 18X12X6 Iron Junction Box
• UNSPSC: 39121314
• UPC 12 Digit: 781381843935
