Appleton DTX241208 24X12X8 Iron Junction Box

Product Specifications

• Part Number: DTX241208
• UPC: 78138184403
• UPC: 781381844031
• Depth: 8-5/16 INCH
• Depth in inch: 8.3125
• Material: CAST IRON
• Finish: HOT DIP GALVANIZED
• Enclosure: NEMA 4/9EFG
• Mounting: LUGS, SURFACE
• Cover Type: GASKETED, BOLT ON
• Approval: UL 886
• Height in inch - UOM: in
• Width in inch - UOM: in
• Depth in inch - UOM: in
• Additional Information: APPLICATION COAL STORAGE UNIT, GRAIN ELEVATOR, TEXTILE FACTORY, TISSUE PAPER MILL; CONSTRUCTIONAL FEATURE DUST IGNITION PROOF, WATER TIGHT
• Brand Name: Appleton.
• Model: DTX
• Type: FLANGED
• Height: 27-3/16 INCH
• Height in inch: 27.1875
• Width: 15-3/16 INCH
• Width in inch: 15.1875
• Full Technical Description: 27.19 Inch Length X 15.19 Inch Width X 8.63 Inch Depth Overall Size; 24 Inch Length X 12 Inch Width X 8 Inch Depth Inner Size; 2 Inch Hub Size; UL 886 Approval; Surface Mounting; Class II Div 1 and 2 Group E F G, Class III, NEMA 4/9FG Enclosure; Gasketed Cover Type; Cast Iron Body Material; Cast Iron Cover Material; 0.31 Inch Wall Thickness; Hot Dip Galvanized Body Finish; 24 Inch Cover Opening Diameter; Hot Dip Galvanized Cover Finish; Constructional Feature Dust Ignitionproof, Water Tight; Application Grain Elevator, Grain Storage Area, Paper Mill, Coal Storage Facility, Textile Factory; Applicable Standard Nec/Cec; DTX Model
• Manufacturer: Appleton Electric
• UNSPSC: 39121314
