Appleton EBR6023HFB60 60A Interlock Receptacle with Breaker

Overview

APP EBR6023HFB60 Appleton 60A 600V Powertite Explosion-Proof Mechanical Interlock Receptacle with Circuit Breaker

Product Specifications

• Catalog Description: Powertite Mechanical Interlock Receptacle; 60 Amp; 600 Volts AC; Single Phase; 3 Pole; 2 Wire; Integrated 60 Amp Circuit Breaker; Explosion-Proof Aluminum Enclosure.
• Category: Plugs & Receptacles
• Full Technical Description: Powertite Mechanical Interlock Receptacle; Integrated Circuit Breaker; 60 Amp Current Rating; 600 Volt AC Rating; Single-Phase Configuration; 3 Poles; 2 Wires; Grounded Design; FD-Type 600 Volt AC Circuit Breaker; Non-Fused Protection; Brass Contacts; Fiberglass-Reinforced Polyester Insulation; Quick-Disconnect Wire Terminals; Epoxy Powder Coated Aluminum Housing; 1-1/2 Inch Feed-Through Hub; Screw Cap Included; Mounting Hardware Included; Knob-Type Locking Handle; Padlockable Enclosure; Waterproof Construction; NEMA 3, 3R, 4, 4X, 7CD, and 9FG Enclosure Ratings; Suitable for Class I Divisions 1 and 2 Groups C and D; Class II Divisions 1 and 2 Groups F and G; Class III Divisions 1 and 2; UL 1010, UL 1203, UL 1682, and UL 894 Standards; UL File Numbers E10784, E313360, and E79132
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Mechanical Interlock Receptacle with Circuit Breaker
• Unspsc: 39121406
• UPC 12 Digit: 781381140694
• SKU Name: APP EBR6023HFB60
