Product information
Overview
APPLETON ELECTRIC N1D75F13 Tumbler Switch, 30A, 120-277Vac, 1 Pole
Product Specifications
- Full Technical Description: Tumbler Switch, 30A, 120-277Vac, 1 Pole | BK2UBY
- Catalog Number: N1D75F13
- Manufacturer: APPLETON ELECTRIC
- Height: 15.24 cm
- Length: 24.13 cm
- Width: 17.78 cm
- Country Of Origin: US
- Weight: 0.126 kg
- Amps: 30A
- Box Type: Single Gang
- Constructional Feature: Explosion Proof, Rain Tight, Water Tight
- Contact Configuration: 1 Pole
- Enclosure: Class I Division 1 And 2 Group C D, NEMA 3/4X/7Cd/12
- Enclosure Material: Glass Reinforced Thermoplastic Polyetherimide
- Hub Size: 1/2", 3/4"
- Type: Dead End
- Voltage: 120-277V AC
