N1DC75F23 Appleton Switches, Intraground N1 Series, DIV 1 30A 120-277VAC 2P SWITCH

Product Specifications

• Catalog Number: N1DC75-F23
• Manufacturer: Appleton
• Family Series: Appleton Switches, Intraground N1 Series
• Product Series: Intraground N1
• Full Technical Description: Explosionproof Tumbler Switch, Type Feed Through, Constructional Feature Explosionproof, Raintight, Watertight, Voltage Rating 120 to 277 VAC, Current Rating 30 Ampere, Contact Configuration 2-Pole, Box Type Single Gang, Hub Size 1/2 Inch or 3/4 Inch
• Voltage: 120-277 VAC
• Switch Type: 2-Pole
• Type of Operator: Front Operated
• Current Rating: 30 A
• Horsepower: 2 hp @ 120 VAC, 2 hp @ 240 VAC
• Hub Size: 1/2 ", 3/4 "
• Number of Gangs: 1
• Material: Polyetherimide
• Mounting: Mounting Holes
• Enclosure: Feed-Thru
• NEMA Rating: NEMA 12, NEMA 3, NEMA 4X, NEMA 7CD
• Approvals: UL
• Comments: Explosionproof
• Net Weight: 0 lbs
• Gross Weight: 3.6 lbs
