Blackburn CTL500-12 Copper Test Point 1-Hole Lug Short Barrel 500 1/2B Brown

Overview

Blackburn CTL500-12 Copper Test Point 1-Hole Lug Short Barrel 500 1/2B Brown

Product Specifications

• UPC: 78378613194
• Number Of Pad Holes: 1
• Stud Size: 1/2 Inch
• Color: Brown
• Die Index: 33, 87
• Material: Tin Plated Seamless Copper
• Overall Length: 3-1/4 Inch
• Approval: UL, CSA
• Catalog Number: CTL500-12
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 500 KCMIL
• Barrel Type: Short, Straight
• Barrel Length: 1-13/32 Inch
• Pad Size: 1-1/4 Inch L x 1-19/32 Inch W x 7/32 Inch Thk
• Catalog Description: COPPER ONE-HOLE LUG, SHORT BARREL, MAX 35KV, 500 KCMIL WIRE, 1/2 BOLT SIZE, TIN PLATED, DIE COLOR CODE BROWN
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Brown Color; 3-1/4 Inch Overall Length; 1-13/32 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 500 kcmil Conductor Size; 1/2 Inch Stud Size; 33, 87 Die Index; 1-1/4 Inch L X 1-19/32 Inch W X 7/32 Inch Thk Pad Size; 1 Pad Hole(S); Short, Straight Barrel Type; CTL Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131945
• SKU Name: blkbrn ctl50012

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
