Burndy KA44U 1000 Aluminum/Copper 1-Hole Terminal Lug

Product Specifications

• UPC: 78181037035
• Pad Size: 1.69 Inch L x 1.77 Inch W x 0.5 Inch Thk
• Stud Size: 1/2 Inch
• Overall Length: 3.5 Inch
• Approval: UL 468-A, UL 468-B, CSA
• Additional Information: RoHS Compatible; Installation Torque 550 Lb-Inch
• Catalog Number: KA44U
• Model: KA-U
• Number Of Conductors: 1
• Minimum Conductor Size: 500 KCMIL Stranded
• Maximum Conductor Size: 1000 KCMIL Stranded
• Conductor Material: Aluminum/Copper
• Material: Electro-Tin Plated Aluminum Alloy
• Number Of Pad Holes: 1
• Catalog Description: ALUMINUM UNIVERSAL TERMINAL, 1 HOLE, 500-1000 KCMIL, 5/8" STUD, 1 SCREW, AL/CU RATED, TIN PLATED.
• Category: Large Terminals & Connectors
• Full Technical Description: Electro-Tin Plated Aluminum Alloy Material; 3.5 Inch Overall Length; 500 kcmil Stranded min. Conductor Size; 1000 kcmil Stranded Max. Conductor Size; Aluminum/Copper Conductor Material; UL 468-A, UL 468-B, CSA Approval; 1 Conductor(S); 1/2 Inch Stud Size; 1.69 Inch L X 1.77 Inch W X 0.5 Inch Thk Pad Size; 1 Pad Hole(S); RoHS Compatible; Installation Torque 550 lb-Inch; KA-U Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Mechanical Cable Lug
• Unspsc: 39121408
• UPC 12 Digit: 781810370353
• SKU Name: bur ka44u
