Overview

Burndy TP10-8F Fork- 12- 10 Awg- Vinyl

Product Specifications

• UPC: 78181071068
• Stud Size: #6 to #8
• Temperature Rating: 105 Deg C
• Approval: UL, CSA
• Additional Information: RoHS Compatible; Dimension 0.98 Inch L x 0.31 Inch W; Voltage Rating 600 V; Material Electro Tin Plated Copper; Wire Strip Length 19/64 Inch; Maximum Insulation Diameter 0.26 Inch
• Catalog Number: TP108F
• Brand Name: VINYLUG[TM]
• Model: TP-F
• Type: Smooth Entry
• Minimum Conductor Size: 12 AWG
• Maximum Conductor Size: 10 AWG
• Color: Yellow
• Insulation Type: PVC Insulated
• Catalog Description: INSULATED BRAZED FORK TERMINAL, INSULATED BRAZED FORK TERMINAL, SMOOTH ENTRY, #12-#10, 600V, #6-#8 STUD, VINYL INSULATED, TIN PLATED.
• Category: Small Terminals & Connectors
• Full Technical Description: Smooth Entry Type; Yellow Color; 12 AWG min. Conductor Size; 10 AWG Max. Conductor Size; UL, CSA Approval; 105 Deg C Temperature Rating; #6 to #8 Stud Size; PVC Insulated Insulation Type; VINYLUG[TM] Brand; RoHS Compatible; Dimension 0.98 Inch L X 0.31 Inch W; Voltage Rating 600 V; Material Electro Tin Plated Copper; Wire Strip Length 19/64 Inch; Maximum Insulation Diameter 0.26 Inch; TP-F Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Fork Lug
• Unspsc: 39121405
• UPC 12 Digit: 781810710685
• SKU Name: bur tp108f
