Burndy Y2826R 4/0-2/0 Copper Red Adapter

Overview

Burndy Y2826R 4/0-2/0 Copper Red Adapter

Product Specifications

• UPC: 78181000102
• Outer Diameter: 0.53 Inch
• Length: 1.75 Inch
• Material: High Conductivity Electrolytic Tin Plated Copper
• Additional Information: RoHS Compatible
• Catalog Number: Y2826R
• Brand Name: HYLINK[TM]
• Model: Y-R
• Type: Center Cable Stop
• Voltage Rating: 600 V to 35 KV
• Conductor Material: Copper
• Side A Conductor Size: 4/0 AWG Stranded
• Side B Conductor Size: 2/0 AWG Stranded
• Catalog Description: 4/0 AWG CU LONG BARREL SIZE REDUCED DOWN TO 2/0 AWG WIRE SIZE, INTERNAL CHAMFER, TIN PLATED, UP TO 35KV, PURPLE COLOR CODE, 15 DIE INDEX.
• Category: Small Terminals & Connectors
• Full Technical Description: Center Cable Stop Type; High Conductivity Electrolytic Tin Plated Copper Material; 1.75 Inch; 0.53 Inch Outer Diameter; Copper Conductor Material; 600 V to 35 kV Voltage Rating; 2/0 AWG Stranded Side B Conductor Size; 4/0 AWG Stranded Side A Conductor Size; RoHS Compatible; Y-R Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Reducer
• Unspsc: 39121458
• UPC 12 Digit: 781810001028
• SKU Name: bur y2826r
