Overview

Burndy YHO-2 2/0 Aluminum/Copper Tap Connector

Product Specifications

• UPC: 78181013903
• Minimum Tap Conductor Size: 6 AWG (ACSR), 6 AWG (Copper/Aluminum/ACSR, Compact), 6 AWG Solid/Stranded
• Maximum Tap Conductor Size: 2 AWG (ACSR), 1 AWG (Copper/Aluminum/ACSR, Compact), 1 AWG Stranded, 1/0 AWG Solid
• Die Index: O
• Body Material: Aluminum
• Approval: CSA
• Additional Information: RoHS Compatible; Size 1.69 Inch L x 0.64 Inch W x 1.12 Inch H
• Catalog Number: YHO2
• Brand Name: LOKTAP[TM]
• Model: YHO
• Shape: H
• Number Of Taps: 1
• Conductor Material: Copper/Aluminum/ACSR
• Minimum Run Conductor Size: 3 AWG (ACSR), 3 AWG Stranded, 2 AWG (Copper/Aluminum/ACSR, Compact), 1 AWG Solid
• Maximum Run Conductor Size: 1/0 AWG (ACSR), 1/0 AWG (ACSR, Compact), 2/0 AWG (Copper/Aluminum, Compact), 2/0 AWG Solid/Stranded
• Catalog Description: WIDE RANGE, UNIVERSAL FIGURE H SHAPED ALUMINUM CONNECTOR. MASSIVE ALUMINUM DESIGN MINIMIZES EFFECTS OF GALVANIC CORROSION. PRE-FILLED WITH PENETROX AND STRIP SEALED TO LIMIT OXIDE GROWTH AND INCREASE THE LIFE OF THE CONNECTION,1.12 H,1.50 L,.64 W.
• Category: Large Terminals & Connectors
• Full Technical Description: 3 AWG (ACSR), 3 AWG Stranded, 2 AWG (Copper/Aluminum/Acsr, Compact), 1 AWG Solid min. Run Conductor Size; 1/0 AWG (ACSR), 1/0 AWG (ACSR, Compact), 2/0 AWG (Copper/Aluminum, Compact), 2/0 AWG Solid/Stranded Max. Run Conductor Size; 6 AWG (ACSR), 6 AWG (Copper/Aluminum/Acsr, Compact), 6 AWG Solid/Stranded min. Tap Conductor Size; 2 AWG (ACSR), 1 AWG (Copper/Aluminum/Acsr, Compact), 1 AWG Stranded, 1/0 AWG Solid Max. Tap Conductor Size; H Shape; Copper/Aluminum/Acsr Conductor Material; CSA Approval; Aluminum Body Material; O Die Index; 1 Tap(S); LOKTAP[TM] Brand; RoHS Compatible; Size 1.69 Inch L X 0.64 Inch W X 1.12 Inch H; YHO Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Sub Category: Compression Cable Tap
• Unspsc: 39121427
• UPC 12 Digit: 781810139035
• SKU Name: bur yho2
