Overview

Burndy YRA4CU1 2-4 Aluminum/Copper 2-Hole Lug

Product Specifications

• Catalog Description: AL COMPRESSION LUG FOR JOINING AL AND CU CABLE TO TRANSFORMER AND EQUIPMENT PADS, PREFILLED WITH PENETROX, PAD WIDTH: .91 IN.
• Full Technical Description: Aluminum Material; 2-9/16 Inch Overall Length; ACSR, Aluminum, Copper Conductor Material; 9/16 Inch Stud Size; BG, 243 Die Index; 1-1/16 Inch Length X 15/16 Inch Width Pad Size; 1 Pad Hole(S); 4 AWG ACSR Conductor Size; 4 AWG Stranded to 2 AWG Solid (Aluminum Concentric/Compact/Copper) Aluminum/Copper Conductor Size; HYLUG[TM] Brand; RoHS Compliant; YRA Model
• Manufacturer: BURNDY PRODUCTS
• Sub Category: Compression Terminal
• UPC 12 Digit: 781810016893
• SKU Name: bur yra4cu1
