Overview

Burndy YS27-LBOX 3/0Str Copper Compression Splice

Product Specifications

• UPC: 78181055650
• Barrel Type: Short with Chamfered
• Length: 2.3 Inch
• Outer Diameter: 0.62 Inch
• Body Material: Electro Tin Plated Copper
• Approval: UL, CSA
• Additional Information: RoHS Compliant; Wire Strip Length 1-1/16 Inch; Die Index 14; Temperature Rating 90 Deg C
• Catalog Number: YS27LBOX
• Brand Name: HYLINK[TM]
• Model: YS-L
• Type: Butt with Center Wire Stop
• Voltage Rating: 35 Kilovolt
• Conductor Size: 3/0 AWG Stranded
• Conductor Material: Copper
• Color Code: Orange
• Catalog Description: 3/0 AWG CU, STANDARD BARREL, INTERNAL CHAMFER, TIN PLATED, UL/CSA, 90C, UP TO 35KV, ORANGE COLOR CODE, 14 DIE INDEX.
• Category: Large Terminals & Connectors
• Full Technical Description: Butt With Center Wire Stop Type; 2.3 Inch; 0.62 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; Electro Tin Plated Copper Body Material; 3/0 AWG Stranded Conductor Size; Orange Color Code; Short With Chamfered Barrel Type; Hylink Brand; RoHS Compliant; Wire Strip Length 1-1/16 Inch; Die Index 14; Temperature Rating 90 Deg C; YS-L Model
• Made In Usa: Yes
• Manufacturer: Burndy Products
• Manufacturer Brand: Burndy Products
• Proposition 65 Warning (Ca): Warning: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 781810556504
• SKU Name: bur ys27lbox
