Bussmann frnr50

Overview

FRNR50 - 50A 250V TD Class RK5 Dual Elem Fuse-Fusetron

Product Specifications

• Catalog Number: FRNR50
• UPC / GTIN: 051712101806
• Manufacturer: Eaton Bussmann Series
• UNSPSC: 39121606 - Cartridge fuses
• Full Technical Description: Time Delay Fusetron Fuse, RK5 Class Fuse, Dual Element Fuse, 10 s @ 500% Response Time, Ferrule End x Ferrule End Connection, 50 A, 250 V ac;125 V dc, Ferrule Terminal, 0.81 in Diameter, 3 in Overall Length, 0.12 lb
• Amperage Rating: 50
• Connection: Ferrule End X Ferrule End
• Current Rating: 50 A
• Interrupt Rating: 200 kAIC (RMS Symmetrical):20 kAIC (DC)
• Terminal Type: Ferrule
• Voltage Rating: 250 V ac;125 V dc
• Diameter: 0.81 in
• Overall Length: 3 in
• Size: 0.81 In Diameter X 3.00 In Length
• Description: 50A 250V TD CLASS RK5 DUAL ELEM FUSE-FUSETRON
• Extra Long Description: BUSS FRN-R-50 FUSETRON DUAL-ELEMENT
• Features: Eaton Bussmann(R) series advanced protection, energy efficient FRN-R Class RK5 dual element, current-limiting, time-delay fuses with optional open fuse indication on select ratings. Time-delay – 10 seconds (minimum) at 500% of rated current (8 seconds for 110-30A sizes).
• Long Description: Time Delay Fusetron Fuse, RK5 Class Fuse, Dual Element Fuse, 10 s @ 500% Response Time, Ferrule End x Ferrule End Connection, 50 A, 250 V ac;125 V dc, Ferrule Terminal, 0.81 in Diameter, 3 in Overall Length, 0.12 lb
• Product Type: Time Delay Fusetron Fuse
• Short Description: Fusetron Fuse, 50 A, 250 VAC/125 V dc, Time Delay, RK5 Class
• Connection Type: Ferrule End x Ferrule End
• Dimensions: 3.0000 IN X 0.8100 IN X 0.8100 IN
• Element: Dual
• Fuse Class: RK5 Class
• Fuse Type: Dual Element
• Made In USA: yes
• Package Quantity: 10 CT
• Response Time: 10 s @ 500%
• Standards Met: UL Listed;STD. 248-12;Class RK-5, Guide JDDZ, File E4273;CSA Certified;C22.2 No. 248.12, Class 1422-02, File 53787;CE Certified
• Brand: Eaton
• Manufacturers Part Number: FRN-R-50
• GTIN: 00051712101806
• UPC: 051712101806
• Type: FUSE
• Weight: 0.12 lb
• Weight per each: 0.12
• Carton: 10
• Application: Combination Starters;Motor Control Centers;Machinery Disconnects;Power Panelboards
• Standard: CE Marked
