Overview

Bussmann NO.2661-R Non-Indicating Fuse Reducer, 250/600 V, 600 A, Class: R, 100 A Fuse

Product Specifications

• Catalog Number: NO.2661-R
• UPC: 051712613774
• Manufacturer Brand: Eaton Bussmann series
• UNSPSC: 39121617
• Features: Fuse reducers install on fuses and permit smaller size fuses to be used in larger amp size switches and blocks; Reducers fit into most panels or switches including the dead front type; Strong contact is maintained both mechanically and electrically; There are no reducers to go from 250 to 600 VAC; There are no reducers for switching from one class to another
• Amperage Rating: 600 A
• Class: R
• Country of Origin: Mexico
• Fuse Block Size: 600 A
• Fuse Size: 100 A
• Type: Non-Indicating
• Voltage Rating: 250/600 V
