Crouse-Hinds STA8 3" Alum Insulated Hub

Overview

High-efficiency motor for reduced energy consumption, Corrosion-resistant materials for enhanced durability, Compact design for easy installation in tight spaces, Adjustable flow rate to meet specific application needs

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES MYERS SCRU-TITE BASIC HUB, ALUMINUM, 3"
• Full Technical Description: Threaded Type; Natural Aluminum (Body/Nut), Nitrile (O-ring Gasket) Material; Rigid/Imc Used on; UL 514B, CUL, CSA C22.2 Approval; 3 Inch Trade Size; NEMA 2/3/3R/4/4X/12, IP66, Vibrationproof, Chemical Resistance, Water Tight, Dust Tight; Insulated Throat Type; MYERS[TM], SCRU-TITE[R] Brand; Enclosure Rating Class I Div 2, Class II Div 1 and 2, Class III Div 1 and 2, Class I Zone 1 Aex E II, Class I Zone 1 Ex E II; Application Hazardous Location; Temperature Rating -15 to 120 Deg C; Applicable Standard Nec/Cec, IEC; STA Model
• Manufacturer: EATON CROUSE-HINDS MYERS HUBS
• Sub Category: Rigid/EMT Conduit Hub
• Unspsc: 39121311
• UPC 12 Digit: 784731100221
• SKU Name: MYERS STA8
