Crouse-Hinds CPH7914 3W-4P Plug

Overview

Crouse-Hinds CPH7914 3W-4P Plug

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES ARKTITE CPH PLUG, 7A/30A, 0.875-1.375" CABLE DIAMETER, THREE-WIRE, FOUR-POLE, BRASS OR COPPER CONTACTS, STYLE 2, 1 HP/3 HP, COPPER-FREE ALUM, 3-PHASE, MECHANICAL CABLE GRIP AND NEOPRENE BUSHING, 120-240/480 VAC
• Full Technical Description: Natural Finished Copper Free Aluminum Material; 0.875 Inch min. Cable Outer Diameter; 1.375 Inch Max. Cable Outer Diameter; 3 Wire(S); 3 Phase(S); UL 1010, CSA C22.2 Approval; 120 to 240 VAC, 480 VAC Voltage Rating; Class I Div 1 and 2 Group C D Enclosure; 30 Ampere at 125 to 240 VAC, 7 Ampere at 480 VAC Current Rating; 3 HP at 125 to 240 VAC, 1 HP at 480 VAC Power Rating; 4 Pole(S); Ces/Cesd Mating Receptacle; ARKTITE[R] Brand; Application Corrossive, Damp, Hazardous, Wet Location; Constructional Feature Explosionproof; Size 6-7/16 Inch L X 2-3/8 Inch W; CPH Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Pin and Sleeve Plug
• Unspsc: 39121402
• UPC 12 Digit: 782274173702
• SKU Name: crsh cph7914
