Product information
Overview
Crouse-Hinds DSD940 Dp Tumb-Switch
Product Specifications
- Catalog Description: EATON CROUSE-HINDS SERIES DSD SNAP SWITCH COVER AND DEVICE SUB-ASSEMBLY, 30A, 2-POLE, FERALOY IRON ALLOY, 120/277 VAC
- Full Technical Description: Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy Material; Eds/Efs Series Control Station Used on; UL 1203, CSA C22.2 Approval; Class I Div 1 and 2 Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F/9G Enclosure; Explosionproof, Dust-Ignitionproof, Raintight; Application Wet Location; Current Rating 30 Ampere at 120/277 VAC; Mounting Surface; Number of Pole 2
- Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
- Sub Category: Explosionproof Selector Switch Cover
- Unspsc: 39122209
- UPC 12 Digit: 782274045146
- SKU Name: crsh dsd940
