Crouse-Hinds EFDC3591 Enclosure W/Thumb Switch

Overview

Crouse-Hinds EFDC3591 Enclosure W/Thumb Switch

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES EFD SNAP SWITCH, 30A, SINGLE-POLE, WITH SWITCH, FERALOY IRON ALLOY, SINGLE-GANG, THROUGH FEED, 1", 120/277 VAC
• Full Technical Description: Feed Through Type; 1-Pole Contact Configuration; 1 Inch Hub Size; Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy Enclosure Material; UL 1203, CSA C22.2 Approval; 120/277 VAC Voltage Rating; Class I Div 1 and 2 Group B C D, Class II Div 1 Group E F G, Class II Div 2 Group F G, Class III, NEMA 3/7B/7C/7D/9E/9F/9G/12 Enclosure; 30 Ampere Current Rating; Explosionproof, Dust-Ignitionproof, Raintight; Front Operated Lever Operator Type; Natural Stainless Steel Actuator Material; Single Gang Box Type; Applicable Standard CEC, NEC; Application Wet Location; Size 6-3/32 Inch L X 3-1/2 Inch W X 3-1/16 Inch D; EFD Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Tumbler/Snap Switch Control Station
• Unspsc: 39121601
• UPC 12 Digit: 782274277608
• SKU Name: crsh efdc3591

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
