Crouse-Hinds EYSR7 2-1/2" Seal Fitting

Overview

Crouse-Hinds EYSR7 2-1/2" Seal Fitting

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES EYSR RETROFIT SEALING FITTING, FERALOY IRON ALLOY, 2-1/2"
• Full Technical Description: Drain, Hub Type; Electrogalvanized Aluminum Acrylic Painted Feraloy Iron Alloy/Ductile Iron Material; Female Connection Type; UL, CSA C22.2 Approval; Class I Div 2 Group C D, Class II Div 2 Group E F G Enclosure; 2-1/2 Inch Trade Size; Vertical/Horizontal Mounting Position; Constructional Feature Explosionproof, Dust-Ignitionproof; Material Electrogalvanized Steel (Pipe Plug, Bolt, Set Screw), Neoprene (Gasket); Internal Volume 48 Cu Inch (Vertical), 75-1/2 Cu Inch (Horizontal) Cu Inch (Horizontal); Size 7-1/2 Inch L X 5 Inch W; EYSR Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Explosionproof Conduit Seal
• Unspsc: 39131708
• UPC 12 Digit: 782274793450
• SKU Name: crsh eysr7
