Crouse-Hinds V2PC22 220/240V Photocell

Overview

Crouse-Hinds V2PC22 220/240V Photocell

Product Specifications

• Catalog Description: EATON CROUSE-HINDS SERIES V2PC PHOTOCELL, 1.8A, 50/60 HZ, PHOTOCELL FOR FIELD INSTALLATION IN LIGHTING FIXTURES, USED WITH LMV, DMV, VMV, VMV HIGH WATTAGE, FMV SERIES LUMINAIRES, 208-240 VAC
• Full Technical Description: Photocell Type; Corrosion Resistant Thermoplastic Polyester Material; Dmv/Fmv/Lmv/N2MV/Vmv Series Champ Lighting Fixture Used on; UL 844, CSA C22.2 Approval; 208 to 240 VAC at 50/60 Hz Voltage Rating; FS Box Mounting; Class I Div 2 Group A B C D Enclosure; 1.8 Ampere Current Rating; 35 to 400 W Lamp Wattage; 6 Inch 600 V Wire Lead Terminal Type; Turn Off Light Level 8 Fc; Turn on Light Level 3 Fc; V2PC Model
• Manufacturer: EATON CROUSE-HINDS INDUSTRIAL
• Sub Category: Vaporproof HID Lighting Photocontrol
• Unspsc: 39122238
• UPC 12 Digit: 782274709369
• SKU Name: crsh v2pc22

Resources

• Product Spec Sheet
• Manufacturer Spec Sheet
