Blackburn CTL20-12 Copper Test Point 1-Hole Lug Short Barrel 2/0 1/2B Black

Overview

Blackburn CTL20-12 Copper Test Point 1-Hole Lug Short Barrel 2/0 1/2B Black

Product Specifications

• UPC: 78378613185
• Number Of Pad Holes: 1
• Stud Size: 1/2 Inch
• Color: Black
• Die Index: 45, 106
• Material: Tin Plated Seamless Copper
• Overall Length: 2-11/32 Inch
• Approval: UL, CSA
• Catalog Number: CTL20-12
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 2/0 AWG Stranded
• Barrel Type: Short
• Barrel Length: 13/16 Inch
• Pad Size: 1-1/4 Inch L x 13/16 Inch W x 1/8 Inch Thk
• Catalog Description: COPPER ONE-HOLE LUG, SHORT BARREL, MAX 35KV, 2/0 STR. WIRE, 1/2 BOLT SIZE, TIN PLATED, DIE COLOR CODE BLACK
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Black Color; 2-11/32 Inch Overall Length; 13/16 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 2/0 AWG Stranded Conductor Size; 1/2 Inch Stud Size; 45, 106 Die Index; 1-1/4 Inch L X 13/16 Inch W X 1/8 Inch Thk Pad Size; 1 Pad Hole(S); Short Barrel Type; CTL Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131853
• SKU Name: ctl2012 blkbrn
