Blackburn CTL5002 Copper Test Point 2-Hole Lug Short Barrel 500 1/2B Brown

Overview

Blackburn CTL5002 Copper Test Point 2-Hole Lug Short Barrel 500 1/2B Brown

Product Specifications

• UPC: 78378641049
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1-3/4 Inch
• Stud Size: 1/2 Inch
• Color: Brown
• Die Index: 33, 87H
• Material: Tin Plated Seamless Copper
• Overall Length: 5 Inch
• Approval: UL, CSA
• Additional Information: Application Regular Duty, Conned Area
• Catalog Number: CTL5002
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 500 KCMIL
• Barrel Type: Short, Straight
• Barrel Length: 1-3/8 Inch
• Pad Size: 3 Inch L x 1-17/32 Inch W x 7/32 Inch Thk
• Catalog Description: TYPE CTL COPPER TWO-HOLE LUG, SHORT BARREL, MAX 35KV, WIRE SIZE 500 KCMIL, 1/2 INCH BOLT SIZE, TIN PLATED, DIE COLOR CODE BROWN
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Brown Color; 5 Inch Overall Length; 1-3/8 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 500 kcmil Conductor Size; 1/2 Inch Stud Size; 33, 87H Die Index; 3 Inch L X 1-17/32 Inch W X 7/32 Inch Thk Pad Size; 2 Pad Hole(S); 1-3/4 Inch Pad Hole Spacing; Short, Straight Barrel Type; Application Regular Duty, Conned Area; CTL Model
• Manufacturer: THOMAS & BETTS BLACKBURN
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786410491
• SKU Name: ilsco ctl5002
