Killark JALX-30 1" Conduit Body & Blank Cover

Overview

Killark JALX-30 1" Conduit Body & Blank Cover

Product Specifications

• UPC: 78393636528
• Shape: Square
• Number Of Plugs: 3
• Cover Type: Screw, Blank
• Cover Opening Diameter: 3-3/4 Inch
• Enclosure: Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III
• Material: Natural Copper Free Aluminum
• Mounting: (2) Lug
• Approval: UL, CSA
• Additional Information: Includes Blank Cover; Application Pulling, Splicing and Maintenance
• Catalog Number: JALX-30
• Model: JAL
• Style: X
• Hub Size: 1 Inch
• Hub Type: Internal
• Number Of Hubs: 4
• Hub Location: (4) Side
• Capacity: 26.5 Cu Inch
• Catalog Description: JALX SERIES - ALUMINUM OUTLET BODY WITH COVER - WITH BLANK COVER - BOX HUB SIZE 1 INCH - COVER HUB SIZE 1/2 INCH
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Natural Copper Free Aluminum Material; Square Shape; 1 Inch Hub Size; 4 Hub(S); UL, CSA Approval; (2) Lug Mounting; Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III Enclosure; Screw, Blank Cover Type; 26.5 Cu Inch Capacity; X Style; 3 Plug(S); (4) Side Hub Location; Internal Hub Type; 3-3/4 Inch Cover Opening Diameter; Includes Blank Cover; Application Pulling, Splicing and Maintenance; JAL Model
• Made In Usa: Yes
• Manufacturer: KILLARK ELECTRIC MANUFACTURING CO.
• Manufacturer Brand: Killark Electric Manufacturing Co.
• Sub Category: Explosionproof Conduit Outlet Box
• Unspsc: 39121314
• UPC 12 Digit: 783936365282
• SKU Name: klrk jalx30

Resources

• Manufacturer Spec Sheet
