Overview

Killark JLC-20 3/4" Aluminum JLC Type W

Product Specifications

• UPC: 78393636562
• Shape: Square
• Cover Type: Screw, Blank
• Cover Opening Diameter: 2-3/8 Inch
• Enclosure: Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III
• Material: Natural Copper Free Aluminum
• Mounting: (2) Lug
• Approval: UL, CSA
• Additional Information: Includes Blank Cover; Application Pulling, Splicing and Maintenance
• Catalog Number: JLC-20
• Model: JLC
• Style: C
• Hub Size: 3/4 Inch
• Hub Type: External
• Number Of Hubs: 2
• Hub Location: Feed Through
• Capacity: 12.5 Cu Inch
• Catalog Description: JL SERIES - ALUMINUM OUTLET BODY WITH COVER - WITH BLANK COVER - BOX TYPE C - BOX HUB SIZE 3/4 INCH - COVER HUB SIZE 1/2 INCH
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Natural Copper Free Aluminum Material; Square Shape; 3/4 Inch Hub Size; 2 Hub(S); UL, CSA Approval; (2) Lug Mounting; Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III Enclosure; Screw, Blank Cover Type; 12.5 Cu Inch Capacity; C Style; Feed Through Hub Location; External Hub Type; 2-3/8 Inch Cover Opening Diameter; Includes Blank Cover; Application Pulling, Splicing and Maintenance; JLC Model
• Made In Usa: Yes
• Manufacturer: Killark Electric Manufacturing Co.
• Manufacturer Brand: Killark Electric Manufacturing Co.
• Sub Category: Explosionproof Conduit Outlet Box
• Unspsc: 39121314
• UPC 12 Digit: 783936365626
• SKU Name: klrk jlc20

Resources

• Manufacturer Spec Sheet
